All visual indicators in the air cleaner assembly show whether the preset differential pressure has been exceeded at any time – even after the system has been shut down. When the factory set differential pressure is exceeded, the red button pops up and remains until the manual reset.
When the differential pressure decreases, the shift spring returns the piston assembly to its normal position; however, the gap between the magnet and the now extended indicating button is too large for the magnetic force to overcome the button spring force. As a result, the button remains in the extended position until the differential pressure decreases and is manually reset.
INGERSOLL RAND, Detroit, Case
Cross Reference For X002102
DONALDSON X002102 AMC 1059448 ; BADGER-76060628 ; BLUEBIRD-1789114 ; CASE BN68258 ; DART-RAX002102 ; DETROIT DIESEL-23560432 ,DX002102 ; ELGIN-6204010 ; ERICKSON-351868 ; FORD-9576X002102 ; FREIGHTLINER-DNX002102 ; GROVE-7486001919 ; INGERSOLL RAND-35365154 ,58175878 ; JLG-8273260 KENWORTH-RAX002102 ; KOEHRING-8273260 ; KOHLER-273113 ; LULL-10740018 ,P40018 ; OMNIQUIP 8273260 ; OSHKOSH-1538650 ; PETTIBONE-LL847475 ; THOMAS BUILT BUSES-61100116 ; TRAK INTERNATIONAL-8273260 ; UPTIME W8810932 ; WAGNER MINING EQUIPMENT-5540612200 ; WESTERN RAX002102
